SM / 200
Overview
SM200
PD 30 is a bias tire suitable to use in standard conditions.
High resistance against cuts and tread wears with special deep
geometry design.
Properties
Pattern Properties
All Sizes
SM / 200
| TIRE SIZE | PR | LOAD INDEX | SPEED SYMBOL | LOAD CAPACITY (kg) | SPEED LIMIT (km/h) | INFLATING PRESSURE (LB/IN2) | RIM | INFLATED DIMENSIONS | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 2 wheeled maximum load per axle (kg) | 4 wheeled maximum load per axle (kg) | RECOM. (INCHES) | PERMITTED (INCHES) | Section Width Min-Max | OUTER DIAMETER (MM) | ||||||
| 6.50-16C | 10 | 108/107 | L | 2000 | 3900 | 120 | 73 | 4.50 E SDC 41/2J, 41/2K | 5.00E SDC, 5K, 5.50F SDC, 51/2K, 6L | 176 | 748 |
| 7.00-16C | 10 | 113/112 | L | 2300 | 4480 | 120 | 76 | 5.50F SDC | 4.50 E SDC, 5.00 E SDC, 5K, 51/2K, 6.00 SDC, 6L | 198 | 778 |
| 7.50-15C | 10 | 114/112 | L | 2360 | 4480 | 120 | 76 | 6.0G | 5.50F, 6.50H | 212 | 772 |
| 7.50-16C | 10 | 116/114 | J | 2500 | 4720 | 100 | 76 | 6.0G SDC, 6L | 5.50FSDC, 6.50H SDC, 61/2L | 210 | 8 06 |
| 7.50-16C | 14 | 122/121 | J | 3000 | 5800 | 100 | 105 | 6.0, B6.0, 6.0S, 6.00T | 5.0, 5.00S, 5.5, B5.5, 5.5S, 6.5, B6.5, 6.5T | 210 | 806 |
